The objectives of these slides are: - To introduce the notion of a process - a program in execution, which forms the basis of all computation - To describe the various features of processes, including scheduling, creation and termination, and communication - To explore interprocess communication using shared memory and message passing

1. Amrita
School
of
Engineering,
Bangalore
Ms. Harika Pudugosula
Teaching Assistant
Department of Electronics & Communication Engineering

2. 2
 Operation on Procesess
 Process Creation
 Process Termination
 Interprocess Communication - Introduction

3. 3
 Interprocess Communication
 Shared - Memory Systems
 Message - Passing Systems
• Naming
• Synchronization
• Buffering

4. 4
Interprocess Communication
• Processes within a system may be independent or cooperating
• Independent process does not affect and does not get affected by other
process, they don’t share data
• Cooperating process can affect or be affected by other processes,
including sharing data
• Reasons and Advantages of process cooperation
• Information sharing - allow concurrent access of shared files
• Computation speedup - execution of process in parallel fashion
• Modularity - construct the system in a modular fashion
• Convenience - compilation of files in parallel

5. 5
Interprocess Communication
• Cooperating processes need
interprocess communication
(IPC)
• Two models of IPC
• Shared memory systems
• Message passing systems
fig: Communications models. (a) Message passing. (b)
Shared memory

6. Interprocess Communication

7. 7
Interprocess Communication
Shared - Memory Systems
• IPC using shared memory requires communicating processes to
establish a region of shared memory
• Shared-memory region lies in the address space of the process
creating the shared-memory segment
• What happens if other processes wishes to communicate ?

8. Producer-Consumer Problem
• Paradigm for cooperating processes, producer process produces
information that is consumed by a consumer process
• For example, a compiler may produce assembly code that is
consumed by an assembler, client–server paradigm, printer - printer
driver
• Producer - Consumer processes runs concurrently and must be
synchronized
• buffer will reside in a region of memory that is shared by the producer and
consumer processes
• Two types of buffer used in Producer - Consumer problems
• unbounded-buffer
• bounded-buffer
8

9. Producer-Consumer Problem
• unbounded-buffer
- no practical limit on the size of the buffer
- producer - always produces new item
- consumer - waits for new items
• bounded-buffer
- there is a fixed buffer size
- producer - consumer has to wait
producer - if buffer is full
consumer - if buffer is empty
9

10. Bounded-Buffer – Shared-Memory Solution
• Shared data
#define BUFFER_SIZE 10
typedef struct {
. . .
} item;
item buffer[BUFFER_SIZE];
int in = 0; /* points to next free position in the buffer */
int out = 0; /* points to first full position in the buffer */
• Solution is correct, but can only use BUFFER_SIZE-1 elements
10

11. Bounded-Buffer – Producer
item next_produced;
while (true) {
/* produce an item in next produced */
while (((in + 1) % BUFFER_SIZE) == out) ;
/* do nothing */
buffer[in] = next_produced;
in = (in + 1) % BUFFER_SIZE;
}
11

12. Bounded Buffer – Consumer
item next_consumed;
while (true) {
while (in == out)
; /* do nothing */
next_consumed = buffer[out];
out = (out + 1) % BUFFER_SIZE;
/* consume the item in next consumed */
}
12

13. Interprocess Communication – Shared Memory
• An area of memory shared among the processes that wish to
communicate
• The communication is under the control of the users processes not
the operating system.
• Major issues is to provide mechanism that will allow the user
processes to synchronize their actions when they access shared
memory.
• Synchronization is discussed in further classes
13

14. • Mechanism for processes to communicate and to synchronize their
actions
• Message system – processes communicate with each other without
resorting to shared variables or same shared address space
• For example, an Internet chat program
• IPC facility provides two operations:
• send(message)
• receive(message)
• The message size is either fixed or variable
14
Interprocess Communication – Message passing

15. • if the message size is fixed
• system-level implementation is straight - forward
• task of programming more difficult
• if the message size is variaable
• system-level implementation is complex
• task of programming simpler
15
Interprocess Communication – Message passing

16. • If processes P and Q wish to communicate, they need to:
• Establish a communication link between them
• Exchange messages via send/receive
• Implementation issues:
• How are links established?
• Can a link be associated with more than two processes?
• How many links can there be between every pair of
communicating processes?
• What is the capacity of a link?
• Is the size of a message that the link can accommodate fixed
or variable?
• Is a link unidirectional or bi-directional?
16
Interprocess Communication – Message passing

17. • Implementation of communication link
• Physical:
• Shared memory
• Hardware bus
• Network
• Logical:
• Direct or indirect
• Synchronous or asynchronous
• Automatic or explicit buffering
17
Interprocess Communication – Message passing

18. Direct Communication
• Processes must name each other explicitly the recipient or sender
of the communication
• send (P, message) – send a message to process P
• receive(Q, message) – receive a message from process Q
• Properties of communication link
• Links are established automatically
• A link is associated with exactly one pair of communicating
processes
• Between each pair there exists exactly one link
• The link may be unidirectional, but is usually bi-directional
18

19. Direct Communication
• This scheme exhibits symmetry in addressing
• both the sender process and the receiver process must name the other
to communicate
• A variant of this scheme employs asymmetry in addressing
• only the sender names the recipient; the recipient is not required to
name the sender
• send (P, message)—Send a message to process P
• receive(id, message)—Receive a message from any process. The
variable id is set to the name of the process with which communication
has taken place
19

20. Indirect Communication
• Messages are directed and received from mailboxes (also referred
to as ports)
• Each mailbox has a unique id
• Processes can communicate only if they share a mailbox
• Properties of communication link
• Link established only if processes share a common mailbox
• A link may be associated with many processes
• Each pair of processes may share several communication links
• Link may be unidirectional or bi-directional
20

21. • Mailbox sharing
• P1, P2, and P3 share mailbox A
• P1, sends a message to A; P2 and P3 receives from A
• Who gets the message?
• Solutions
• Allow a link to be associated with at most two processes
• Allow only one process at a time to execute a receive operation
• Allow the system to select arbitrarily the receiver. Sender is
notified who the receiver was.
21
Indirect Communication

22. • If mailbox owned by Process
• Mailbox is part of the address space of the process
• Each mailbox has a unique owner
• Distinguish between the owner (which can only receive
messages through this mailbox) and the user (which can only
send messages to the mailbox)
• Mailbox terminates, then mailbox disappears
22
Indirect Communication

23. • If mailbox owned by an OS
• Provides a mechanism that allows a process to do
• Create a new mailbox
• Send and receive messages through the mailbox
• Delete a mailbox
• Can ownership and receiving privileges of mailbox be
passed to other mailbox ?
23
Indirect Communication

24. • Primitives are defined as:
send(A, message) – send a message to mailbox A
receive(A, message) – receive a message from mailbox A
24
Indirect Communication

25. Synchronization
• Message passing may be either blocking or non-blocking
• Blocking is considered synchronous
• Blocking send -- the sender is blocked until the message is
received
• Blocking receive -- the receiver is blocked until a message is
available
• Non-blocking is considered asynchronous
• Non-blocking send -- the sender sends the message and continue
• Non-blocking receive -- the receiver receives:
- A valid message, or
- Null message
• Different combinations possible
• If both send and receive are blocking, we have a rendezvous
25

26. Producer-consumer becomes trivial - when we use blocking send() and
receive() statements
message next_produced;
while (true) {
/* produce an item in next produced*/
send(next_produced);
}
message next_consumed;
while (true) {
receive(next_consumed);
/* consume the item in next consumed */
}
26
Synchronization

27. Buffering
• Communicating processes reside in temporary queue
• Queue of messages attached to the link.
• Implemented in one of three ways
1. Zero capacity – max. length = 0, no messages are queued
Sender must wait for receiver (rendezvous) - with no buffering
2. Bounded capacity – finite length of n messages
Sender must wait if link full
3. Unbounded capacity – infinite length
Sender never waits
- automatic buffering
27

28. 28
References
1. Silberscatnz and Galvin, “Operating System Concepts,” Ninth Edition,
John Wiley and Sons, 2012.
